Boulevard

Boulevard offers ultra high brightness with asymmetric beam patterns for street/flood lighting application.

It is available in two different colors such as white and mixed warm (Pro series). Available in different wattage, it is perfect for streets, traffic routes, building facades, perimeters, car parking and advertising billboards.

It could save substantial energy (>60%) and reduce CO2 emission (>350kg / year) as compared to conventional Mercury or High pressure sodium street lanterns.

Features

Plug-and-play for easy installation
High performance optical system
- Beam Spread: 135°
Light Color: white, mixed warm
Junction Temperature (Tj@Ta=25°C) :
- Boulevard VIII: <53°C
- Boulevard XII: <55°C
- Boulevard X: <60°C
- Boulevard Pro: <60°C
Long useful life: (L₇₀ > 50,000 Hours)

Light Source

Ultra-high-power Light Engine (7W / 10W / 14W)
LEDs Luminous Flux:
- 112W: 11,200 lm
- 120W: 12,000 lm
- 126W: 6,635 lm
- 140W: 1,4000 lm
CCT
- 3,000 - 4,500K (mixed warm)
- 5,000 - 7,000K (white)

Power Supply

Wattages:
- Boulevard: 112W, 120W, 140W
- Boulevard Pro: 126W
Input Voltage: AC100 / 240V, 50-60Hz
Input Current Range:
- 112W: 1395/615 mA
- 120W: 1490/675 mA
- 126W: 1550/685 mA
- 140W: 1740/790 mA
System Power Consumption:
- 112W: ≤ 137W
- 120W: ≤ 146W
- 126W: ≤ 154W
- 140W: ≤ 171W
Driving Current: Constant
